A255
Single arm lift model
Our latest model of in-vehicle single-arm lift offers an even more satisfying user experience, thanks to the complete automation of the device. The A255 wheelchair lift is automatic in its up and down operations, and swivels in and out of the vehicle once closed, to facilitate loading/unloading of luggage and access to the vehicle.
Warranty
24 months
certified
in accordance with CE regulations
| Technical features | Dimensions | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Article | Max Capacity | Weight | Power supply | Max Lifting height | A | B | C | D | E | F | G |
| A255 - R | 250kg | 90kg | 12 V | 75cm | 98,2cm | 37,1cm | 98,2cm | 89,15cm | 97,65cm | 75cm | 112,4cm |
| A255 - L | 250kg | 90kg | 12 V | 75cm | 98,2cm | 37,1cm | 98,2cm | 89,15cm | 97,65cm | 75cm | 112,4cm |
| A255 XS - R | 250kg | 85kg | 12 V | 75cm | 98,2cm | 37,1cm | 98,2cm | 84cm | 90cm | 70cm | 112,4cm |
| A255 XS - L | 250kg | 85kg | 12 V | 75cm | 98,2cm | 37,1cm | 98,2cm | 84cm | 90cm | 70cm | 112,4cm |
Remote control kit for a remote operation of the lift
Flashing LEDs on vertical columns
Emergency hand pump to be operated in the event of malfunction or power failure
Battery cut-off switch
Automatic safety flap for locking wheelchair
Automatic vehicle connection flap
Anti-tilt device
Double microswitch
Recommended for small vehicles, the lift arm can be requested either on the right or left side.
